Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
OBL
64
320
25
8
Sternum View
AP
60
320
30
9.6
LAT
48
320
4
1.28
OBL
48
320
7
2.24
C-Spine
AP
66
320
50
16
LAT
64
320
35
11.2
OBL
62
320
35
11.2
L-Spine
AP
72
320
80
25.6
LAT
78
320
110
35.2
OBL
72
320
90
28.8
T-Spine
AP
67
320
50
16
LAT
76
320
55
17.6
OBL
70
320
50
16
Abdomen
AP
70
320
50
16
LAT
74
320
60
19.2
OBL
70
320
55
17.6
Pelvis
AP
72
320
70
22.4
LAT
74
320
95
30.4
OBL
70
320
85
27.2
Hip Bone
AP
66
320
20
6.4
LAT
74
320
55
17.6
OBL
75
320
40
12.8
kV
mA
mSec
mAs
Hand
AP
41
320
3
0.96
LAT
40
320
3
0.96
OBL
40
320
3
0.96
Elbow
AP
46
320
7
2.24
LAT
47
320
7
2.24
OBL
44
320
7
2.24
Forearm
AP
47
320
7
2.24
LAT
47
320
7
2.24
OBL
45
320
7
2.24
Foot
AP
46
320
10
3.2
LAT
49
320
10
3.2
OBL
46
320
10
3.2
Ankle
AP
52
320
11
3.52
