HF-525Plus Installation, Operation and Service Manual
5.2.3 Table Bucky (4-Way)
■ Table
√ Physical characteristics
Composition
Size (Unit: mm) deviation ±10%
Weight (Unit: Kg)
Deviation ±5 Kg
Length
Width
Height
Table Bucky
2,200
800
700
140
√ Dimension (unit: mm)
■ Bucky device
√ Physical characteristics
Composition
Size (Unit: mm) deviation ±10%
Weight (Unit: Kg)
Deviation ±5 Kg
Distance between Table top,
Detector
Moving Distance
from left to right
Bucky device
Max. 80 이내
600
60
√ Dimension (unit: mm)
