Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
■ Bucky device
√ Physical characteristics
Composition
Size (Unit: mm) deviation ±10%
Weight (Unit: Kg)
Deviation ±5 Kg
Distance From Table Top To
Detector
Moving
Distance from
Left to Right
Bucky device
Max. 80 or Less
600
60
√ Dimension (unit: mm)
5.2.6 Ceiling tube support unit (Option)
√ Physical characteristics
Composition
Size (Unit: mm) deviation ±10%
Weight (Unit: Kg)
Deviation ±5 Kg
Length
Width
Height
Rail
X-axis Rail
3,500
70
100
Y-axis Rail
630
3,000
120
Wagon
860
755
2360
It could be changeable by X-ray room size
√ Dimension (unit: mm)
