HF-525Plus Installation, Operation and Service Manual
5.10.5.7 Lock cabling
● Locker are Up/ Down, Front/Rear, Left/Right, Column Rotation, Tube Rotation Lock.
● Please pay your attention to the Lock board location – see below photo.
● Make correct cabling for Tube Rotation Lock, Front/Rear Lock.
