Acclarix AX8/Acclarix AX7 Diagnostic Ultrasound System User Manual Measurements and Reports
- 96 -
8.1.2. M-mode Generic Measurements
The generic measurements supported in M-mode are listed in the table below.
No.
Measurement
Group
Measurement Item
Remark
1.
Generic
Distance
2-point method
Slope
Time
HR
8.1.2.1. Distance
The distance measurement measures the distance between two points at the vertical direction. To
measure the distance:
1. Invoke the generic measurement function.
2. Select Dist. 2 Point.
3. Move the caliper to the start point.
4. Press the <Set> key to fix the start point.
5. Move the caliper to the end point.
Presses of the <Update> key will toggle between active calipers, allowing you to adjust the
position of start point and end point.
6. Press the <Set> key to fix the end point and complete the measurement.
8.1.2.2. Slope
The Slope measurement measures the distance and time between two points, and calculates the
slope. To measure Slope:
1. Invoke the generic measurement function.
2. Select Slope.
3. Move the caliper to the start point.
4. Press the <Set> key to fix the start point.
5. Move the caliper to the end point.
Presses of the <Update> key will toggle between active calipers, allowing you to adjust the
position of start point and end point.
6. Press the <Set> key to fix the end point and complete the measurement.
8.1.2.3. Time
The Time measurement measure the time interval between two points. To measure Time:
1. Invoke the generic measurement function.
2. Select Time.
3. Move the caliper to the start point.
4. Press the <Set> key to fix the start point.
5. Move the caliper to the end point.
Presses of the <Update> key will toggle between active calipers, allowing you to adjust the
