EDAN Acclarix AX7 User Manual

Acclarix AX8/Acclarix AX7 Diagnostic Ultrasound System User Manual Specifications
- 171 -
A.4 Machine Specifications
Main unit dimensions
38.8cm(W)x 40.7cm(D)x 7.7cm(H)
Net weight
9.25kg including battery (not including power adaptor or
transducer)
A.5 Display Specifications
Display
TFT-LCD
Diagonal Size
15.6 inches
View Angle
Right 80°, Left 80°, Up 80°, Down 80° (min)
Pixel Number
1920x1080
White Luminance
300 cd/m
2
(typ)
Contrast Ratio
700 (typ)
A.6 Technical Specifications
General Specifications
Display Modes
B Mode: Single, Dual, Quad
C Mode: B/C(Single, Dual, Quad);
B+B/C(Dual Live);
B/C/PW(Triplex mode)
PDI/DPDI Mode:
B/PDI(DPDI) (Single, Dual, Quad);
B+B/PDI(DPDI) (Dual Live);
B/PDI(DPDI)/PW (Triplex mode)
PW Mode:
B/PW;(Update)
B/PW; (duplex, simultaneous)
B/C/PW(Update)
B/C/PW, B/PDI(DPDI)/PW; (triplex mode)
CW Mode:
B/CW;
B/C/CW, B/PDI(DPDI)/CW;
M Mode: B/M (Display layout: Up/down, Left/right,1:1)
TDI Mode:
B+ Color-TDI (Dual Live)
B+PW-TDI (Update)
B+ PW-TDI(duplex, simultaneous)
B+ Color-TDI + PW-TDI (Update)
B+ Color-TDI + PW-TDI ((triplex mode)
