Acclarix AX8/Acclarix AX7 Diagnostic Ultrasound System User Manual Measurements and Reports
- 97 -
position of start point and end point.
6. Press the <Set> key to fix the end point and complete the measurement.
8.1.2.4. HR
The HR measurement measures the time interval between two points, and calculates the heart rate.
To measure HR:
1. Invoke the generic measurement function.
2. Select HR.
3. Move the caliper to the first heartbeat.
4. Press the <Set> key to fix the start point.
5. Move the caliper to the next beat.
Presses of the <Update> key will toggle between active calipers, allowing you to adjust the
position of start point and end point.
6. Press the <Set> key to fix the end point and complete the measurement.
8.1.3. Strip Doppler Generic Measurements
The generic measurements supported in strip Doppler mode are listed in the table below.
No.
Measurement
Group
Measurement Item
Remark
1.
Generic
PS
ED
RI
PI
PS,ED,RI,S/D
Time
HR
Manual Trace
Auto Trace
Spline Trace
2.
Generic
Velocity
Only available for Cardiac
exam
Manual Trace
Spline Trace
HR
Time
PGMax
PGMean
3.
Vessel
Vol Flow
