Acclarix AX8/Acclarix AX7 Diagnostic Ultrasound System User Manual Utilities
- 150 -
Auto zoom image
at shallow depth
on linear
transducer
√/×
Set whether to zoom in the image automatically
when adjusting image depth to shallow depth on
linear transducer.
Hide non
intra-operative
indicator for
L17-7SQ
√/×
Set whether to hide the hint of “non
intra-operative” while using transducer
L17-7SQ.
Single arrow in
comment
√/×
Set whether to add only a single arrow at a time
when adding comments on an image.
Table 11-1 General Set-up Description
11.1.2. Patient Set-up
Figure 11-2 Patient Set-up Screen
Item
Options
Description
Weight Unit
kg, lbs
Set the weight unit of patients.
Height Unit
cm, ft/in
Set the height unit of patients.
Title of custom
field 1/2
/
You can define two additional fields for data entry on
the Patient Information screen.
Time Limit for
Exam Restart
0/12h/24h/48h/72h/
Unlimited
You can define the time limit for restarting exam.
Only exams within the time limit can be restart. If 0
is selected, no exam can be restart.
Patient Name
Display Option
One field/Two fields
You can define the patient name display format.
The patient information page displays “Patient
Name” for one field and displays “Last Name” and
“First Name” for two fields.
Table 11-2 Patient Set-up Description
