Acclarix AX8/Acclarix AX7 Diagnostic Ultrasound System User Manual Measurements and Reports
- 109 -
8.2.4. Cardiac Measurements
No.
Measurement
Group
Measurement
Item
Description
Method
Section 1: B-mode Measurements
1.1
LV Simpson
A4C Dias.
Left Ventricular apical four-chamber
views at End-diastole
Simpson (See
section 8.2.4.1)
A4C Sys.
Left Ventricular apical four-chamber
views at End-systole
A2C Dias.
Left Ventricular apical two-chamber
views at End-diastole
A2C Sys.
Left Ventricular apical two-chamber
views at End-systole
1.2
A/L(LV)
LVd
Left Ventricular Dimension at End
Diastole
Ellipse+1
distance in
B-mode generic
measurements
LVs
Left Ventricular Dimension at End
Systole
1.3
Simp(LA)
LA A4Cs
Left Atrium apical four-chamber
views at End-systole
Simpson (See
section 8.2.4.1)
LA A2Cs
Left Atrium apical two-chamber
views at End-systole
1.4
Simp(RA)
RA A4Cs
Right Atrium apical four-chamber
views at End- systole
1.5
MASS
LVAd Sax Epi
Left Ventricular Epicardial Area at
Papillary Muscle Level at End
Diastole in Short-axis View
Ellipse+1
distance in
B-mode generic
measurements
LVAd Sax Endo
Left Ventricular Endocardial Area at
Papillary Muscle Level at End
Systole in Short-axis View
LVLd Apical
Left Ventricular Long Axis Length at
End Diastole in Apical View
Distance in
B-mode generic
measurements
1.6
LV/RV
RVAWd
Right Ventricular Anterior Wall
Thickness at End-diastole
Distance in
B-mode generic
measurements
RVIDd
Right Ventricular Internal Diameter
at end-diastole
IVSTd
Interventricular Septal Thickness at
End-diastole
IVSTs
Interventricular Septal Thickness at
End-systole
