Acclarix AX8/Acclarix AX7 Diagnostic Ultrasound System User Manual Getting Started
- 10 -
3 Getting Started
3.1 System Configuration
Standard Configuration:
 1 main unit
 1 rechargeable lithium battery
 1 AC adapter
 1 power cord
 1 bottle of coupling gel
 1 basic user manual and 1 advanced user manual
Options:
 Transducers: C5-2XQ, C5-2Q, L10-4Q, L12-5Q, L17-7HQ, E8-4Q, MC8-4Q, P5-1XQ,
L17-7SQ, C5-2MQ, P5-1Q, MC9-3TQ, P7-3Q, C7-2XQ, E10-3BQ, E10-3HQ, C5-1Q
 Needle Guide Bracket Kit
Model
Angle/Depth
Description
BGK-C5-2
20°, 28°, 40°
For use with the C7-2XQ/C5-2Q/C5-2XQ,
Supports: 14G-23G
BGK-L40UB
34°, 43°, 53°, 66°
For use with the L10-4Q/L17-7HQ,
Supports: 14G-23G
BGK-CR10UA
2°
For use with the E8-4Q,
Supports: 16G, 18G
BGK-R15UB
12°, 20°, 35°
For use with the MC8-4Q,
Supports: 14G-23G
BGK-P5-1X
15°, 25°
For use with the P5-1XQ
Supports: 14G-23G
BGK-001
1.0cm, 1.5cm, 2.0cm
For use with the L10-4Q/L17-7HQ,
Supports: 21G
BGK-002
38°, 46°, 58°
For use with the L12-5Q,
Supports: 14G-23G
BGK-003
1.0cm, 1.5cm, 2.0cm
For use with the L12-5Q,
Supports: 21G
BGK-004
12°, 20°
For use with the MC9-3TQ,
Supports: 14G-23G
BGK-005
0°
For use with the E10-3BQ, Supports: 16G, 18G
BGK-006
1°
For use with the E10-3HQ, Supports: 16G, 18G
Table 3-1 Needle Guide Bracket Kits
