Acclarix AX8/Acclarix AX7 Diagnostic Ultrasound System User Manual Measurements and Reports
- 92 -
8.1 Generic Measurements
Each imaging mode supports different types of generic measurements. This chapter describes all the
generic measurements supported in each imaging mode.
8.1.1. B-mode Generic Measurements
The generic measurements supported in B-mode are listed in the table below.
No.
Measurement
Group
Measurement Item
Remark
1.
Distance
Dist. 2 Point
Stenosis% Dist.
2.
Circ/Area
Area Ellipse
Area Trace
Area Spline
Stenosis% Trace
Stenosis% Ellipse
Stenosis% Spline
3.
Angle
Angle 3 Point
4.
Volume
Volume 3 Dist.
Ellipse 1 Dist.
5.
Vessel
Vessel Diam.
2-point distance method
Vessel Area
Ellipse method
Stenosis% Diam.
Stenosis% Area
IMT
2-point distance method
VF Area
2-point distance method
6.
Elastography
Eratio-Area
Only available for
Elastography mode.
Eratio-Trace
7. .
Color
Vel
Only available in Color
mode.
8.1.1.1. Distance
The distance measurement measures the distance between two points.
2-Point Method:
1. Invoke the generic measurement function.
2. Select Distance-> Dist. 2 Point.
3. Move the caliper to the start point.
4. Press the <Set> key to fix the start point.
5. Move the caliper to the end point.
Presses of the <Update> key will toggle between active calipers, allowing you to adjust the
position of start point and end point.
6. Press the <Set> key to fix the end point and complete the measurement.
