EDAN Acclarix AX7 User Manual

Acclarix AX8/Acclarix AX7 Diagnostic Ultrasound System User Manual Specifications
- 172 -
3D/4D: 3D Rendering, 3 Sectional Planes
Elastography:
E, B+E(Display layout: Up/down, Left/right, 1:1);
Hard Drive Storage
120GB (SSD, Standard)
500 GB (HHD, Optional)
Report Packages
Abdomen, Obstetrics, Small Parts, Vascular, Cardiac, Gynecology,
Urology, Pediatric
Wi-Fi Specifications
Standard Conformance
802.11b, 802.11g ,802.11n
Frequency Band
2.412-2.472GHz(@2.4GHz band)
Modulation Technique
OFDM with BPSK, QPSK, 16-QAM, and 64-QAM;
DSSS with DBPSK, DQPSK and CCK;
Typical Transmit Power
(±2dBm)
802.11b: 17dBm
802.11g: 16 dBm
802.11n: 2.4GHz/HT20 @800GI (400GI), 16 dBm
802.11n: 2.4GHz/HT40 @800GI (400GI), 16 dBm
Wi-Fi Quality of Service
Data rate
802.11b: up to 11 Mbps @ 2.4 Ghz
802.11g: up to 54 Mbps @ 2.4 Ghz
802.11n: up to 65 Mbps @ 2.4 Ghz
Data security
WPA2 encryption
Application-layer delay
No requirement. It's not used in real time.
Application-layer
reliability
No requirement. Application failure will be notified to the user
immediately.
System capacity
No more than one device will be allowed to connect with the
ultrasound system.
System anti-interference
Can be coexistent with other Wi-Fi devices.
Network interruption
alarm
Network interruption is notified by disconnection icon and failure in
transmission is notified in Transfer Status window.
EMC test process
Wi-Fi function is not affected when the system is imposed with
radiation interference complied with IEC60601-1-2:2014 standard.
ECG Specifications
Patient Cable
IEC, AHA
Lead Mode
3-Lead: I, II, III
AC Filter
50 Hz, 60 Hz
HR Range and
Accuracy
Adult: 15 bpm to 300 bpm
Pediatric: 15 bpm to 350 bpm
