Acclarix AX8/Acclarix AX7 Diagnostic Ultrasound System User Manual Measurements and Reports
- 107 -
No.
Measurement
Group
Measurement
Item
Description
Method
1.7
LVOT/AO
LVOT Diam
Left Ventricular Outflow
Tract Diameter
Ao Asc
Ascending Aorta Diameter
Ao Arch
Aorta Arch Diameter
Ao Isthmus
Aorta Isthmus Diameter
Desc Ao
Descending Aorta
Diameter
1.8
RVOT/PA
RVOT Diam
Right Ventricular Outflow
Tract Diameter
MPA Diam
Main Pulmonary Artery
Ductus A
Duct Arteriosus Diameter
1.9
CTAR
Area 1
Cardio/Thorax area ratio
Trace in B-mode
generic
measurements
Area 2
Ellipse in B-mode
generic
measurements
Section 2: Doppler Measurements
2.1
MCA
PS
ED
RI
PI
PS,ED,RI,S/D
Time
HR
Auto Trace
Manual Trace
Spline Trace
Middle Cerebral Artery
Doppler generic
measurements
2.2
Umb. A
Umbilical Artery
2.3
Planenta A
Placenta Artery
2.4
Ovary A
Ovary Artery
2.5
Ut. A
Uterine Artery
2.6
Fetal Ao
Fetal Aorta
2.7
Desc Aorta
Descending Aorta
2.8
Ductus V
Ductus Venosus
Velocity in Doppler
generic
measurements
2.9
FHR
Fetal Heart Rate
2.10
MV
Mitral Valve
2.11
TV
Tricuspid Valve
2.12
MPV
Main Pulmonary Vein
2.13
Ductus A
Fetal Aorta
Section 3: M-mode Measurements
3.1
FHR
Fetal Heart Rate
HR in M generic
measurements
* The measurement method including 1 Distance, 2 Distances and 3 Distances can be switched by
