Acclarix AX8/Acclarix AX7 Diagnostic Ultrasound System User Manual Measurements and Reports
- 120 -
No.
Measurement
Group
Measurement
Item
Description
Method
2.32
CIV
Common Iliac Vein
2.33
EIV
External Iliac Vein
2.34
IIV
Internal Iliac Vein
2.35
Saph V
Great Saphenous Vein
2.36
Pop V
Popliteal Vein
2.37
Peron V
Peroneal Vein
2.38
PTV
Posterior Tibial Vein
2.39
ATV
Anterior Tibial Vein
2.40
SSV
Small Saphenous Vein
2.41
HR
Heart Rate
HR in Doppler
generic
measurements
2.42
Vol Flow
Volume Flow
See 8.1.3.8
8.2.7.1. Auto IMT
Intima-media thickness (IMT) is a measurement of the thickness of tunica intima and tunica media.
The system provides an automatic measurement of the Carotid IMT.
To measure IMT:
1. Invoke the B-mode application measurement in Carotid Preset.
2. Select an IMT measurement on the touch screen. A ROI box will be displayed on the image
field.
3. Press the Position or Left/Right paddle key to select a different position of carotid artery.
4. Press <Update> key and use the trackpad to adjust the size of ROI box.
5. Press <Update> key again to confirm the size of ROI box.
6. Use the trackbpad to move the ROI box to desired measurement location, and then the
system automatically displays the IMT measurement results.
7. Press <Set> key to complete measurement and save the results in the worksheet.
8. If you are not satisfied with the measurement result, press Tool Option to switch to Distance
tool and do the IMT measurement manually.
9. The IMT measurement can display the following result:
 Max (the maximum value of the IMT results)
 Min (the minimum value of the IMT results)
 Avg (the average value of the IMT results)
 Width (the width of the ROI box)
 SD (the Standard Deviation of the IMT results)
 Points (the number of valid points in the IMT results)
