EDAN Acclarix AX7 User Manual

Acclarix AX8/Acclarix AX7 Diagnostic Ultrasound System User Manual Getting Started
- 18 -
No.
Shortcut Keys
Description
1
Select All
Selects all the displayed static images and clips.
2
Delete
Deletes the selected static images and clips.
3
Export
Exports the selected static images and clips to removable
storage devices.
4
Next/Previous
Images
Shows next/previous images when more than one page of
images are displayed.
⑤ User Feedback Field
The user feedback filed is displayed below image field and above status bar. This field displays:
 Virtual trackball and trackball keys.
 Cine bar when the system is frozen.
 The active function of user custom key F1 and F2.
⑥ Status Bar
The bottom of the screen is used to display icons that provide system status. These include:
No.
Icons
Description
1
Image Store
icon
Displays the number of static images and clips stored in the
current exam.
2
USB icon
USB available.
3
Printer icon
Printer available.
4
Wi-Fi icon
Wi-Fi function is enabled, but no WI-FI network is
connected.
No WI-FI icon will be displayed when Wi-Fi function is
disabled in Connectivity setup.
Wi-Fi network is connected.
Clicking on this icon shows a list of available Wi-Fi networks.
Selecting an available network displays a dialog box for
entering password. Clicking on the "WiFi: Turn off" button
above the list will disconnect the currently connected WI-FI
network.
