M3 Vital Signs Monitor User Manual Introduction
- 15 -
The Waveform area can display parameter trend list or alarm list. It displays as follows:
Figure 3-3 Main Display with Alarm List
The display on the screen can be changed to a trend graph as follows:
Figure 3-4 Display Trend Graph
②
