M3 Vital Signs Monitor User Manual Introduction
- 24 -
Right side of the monitor
If the monitor has TEMP function, there will be TEMP module and thermometer outfitted on the
right side. Three optional TEMP measurement modules are available: T2 module, TH module
(Infrared Ear Temperature module) and F3000 module. Refer to Figure 3-12.
With T2 TEMP Module:
With Infrared Ear Temperature Module:
T2 TEMP probe
T2 TEMP probe
holder
TH TEMP thermometer
TH TEMP thermometer
holder
