With F3000 TEMP Module:
Figure 3-12 Right Panel
WARNING
Only connect accessories supplied or recommended by EDAN to the device.
Rear Panel
Figure 3-13 Rear Panel of M3
Sockets on the rear panel are shown in the above figure:
① Equipotential grounding terminal for connection with the hospital’s grounding system.
①
②
④
③
F3000 TEMP probe
F3000 TEMP isolation
chamber
