SE-1201 Electrocardiograph User Manual System Setup
- 90 -
Item Description
Record Mode
Choose from: Save Paper or Quickly
Select Save Paper, 10s after pressing the PRINT/STOP key on the main
screen, an ECG report is printed. The patient information, measure
information, interpretation and ECG waves are printed at the same time.
Select Quickly, pressing the PRINT/STOP key on the main screen to
begin printing an ECG report immediately, the patient information,
measure information, interpretation and ECG waves are printed on the
different pieces of paper.
NOTE:
1. In the auto mode, only when Sampling Mode is set to
Real-time Sample, Quickly is available.
2. When Record Style is set to 3×4, 3×4+1R or 3×4+3R, only
Save Paper is available. When Record Style is set to 12×1,
only Quickly is available
Record Sequence
Choose from: Sequential or Synchronous
Select Sequential, the lead group is printed one by one in a certain
sequence. The start time of a lead group is just the end time of the
previous lead group.
Select Synchronous, the lead group is printed one by one in a certain
sequence. All leads are printed with the same start time.
Gain
You can set the indicated height of 1mV ECG on the paper.
Choose from: 10mm/mV, 20mm/mV, 10/5mm/mV, AGC, 2.5mm/mV
or 5mm/mV.
AGC means auto gain control. When ECG signals vary greatly, AGC can
be selected to adjust the gain automatically according to actual signals.
10/5mm/mV means that the gain of limb leads is set to 10mm/mV, while
the gain of chest leads is set to 5mm/mV.
Record Device
Choose from: Thermal, HP 2010/1050/2000 or HP 2015/2035
You should connect the corresponding USB printer HP 2010/1050/2000
and HP 2015/2035 to the electrocardiograph.
WARNING
If the printer used is not the type listed above, additional safety measures (such as
applying an isolation transformer to supply the medical system) should be taken when the
safety of the medical system has not been evaluated. If in doubt, consult our technical
service department or your local distributor.
