Ekra E1 - Page 100

Parts List 2283000011
Universal print nest 550mm
Date of
design:
27.06.2001 Date of change: 14.09.2001 Drawing
73726F
Variation:
Item Var. Quant. Designation Dimension Article
10
1,00
piece
ledge 20*25.4*550 4054000133
20 1,00
piece
stretching ledge 20*25.4*550 4054000134
30 1,00
piece
guidance ledge 30*25.4*550 4054000135
40 4,00
piece
plate 40*5*25.4 4052000186
50 1,00
piece
sheet metal 1.5*17.5*534 4040000239
60 1,00
piece
sheet metal 1.5*40*550 4040000240
70 1,00
piece
sheet metal 2*285*428 4040000241
80 2,00
piece
guidance bolt 10h6*74.5 4034000037
90 5,00
piece
magnet strip 550mm 2283000014
100 1,00
piece
cylinder fixing 20*15*120 4054000132
110 2,00
piece
sheet metal 2*117.5*428 4040000242
120 1,00
piece
sheet metal 1*17.5*550 4040000243
130 1,00
piece
sheet metal 1*40*550 4040000244
140 4,00
piece
pin ISO 28734-5*20-A-St 5*20 5055000010
150 4,00
piece
pin ISO 28734-3*8-A-St 3*8 5055000005
160 2,00
piece
spring DIN 2098-1.10*9.20*26.00
stainless
5023000011
170 4,00
piece
Polymer plain bearing 10*12*14.5 5012050001
180 1,00
piece
tightening unit EV-10/30 stroke 3mm 5027020003
190 1,00
piece
print plate EV-10/30-DP 5027020004
Seite/Page 1
© EKRA
10.04.02
