Chapter 5 Operation
5-2
E1 Semi-automatic screen printer
System Manual
EKRA / Doku Eisermann 05_BEDIEN_PDF.FM
30.8.02
Aligning the PCB
Requirement:
The machine must be ready for operation and in its basic position.
Note:
Always mount the PCB centrally on the table.
Release the two fixing screws holding the clamping strips at the front
and rear.
Align the clamping strips with the PCB such that there is still a gap of
2-3 mm between the edge of the PCB and the clamping strip.
Tighten the two fixing screws holding the clamping strips at the front
and rear.
In the printing nest, position the magnetic strips or magnetic pins to
support the PCB.
Place the PCB in the printing nest. Make sure that the PCB is lying flat
and that it can be clamped.
Turn the PCB clamping switch at the side of the control desk to the "I"
position:
The PCB is clamped.
Note:
If the foot switch is pressed while the printing table is in motion, the
table is immediately stopped and the control voltage is switched off.
After this, press the ON button and press the foot switch again. The
printer performs a reference drive.
