Ekra E1 - Electric Parts List

Chapter 8 Electrical and Pneumatic Equipment
8-10
E1 Semi-automatic screen printer
System Manual
EKRA / Doku Eisermann 08_ELEKTRO_PNEU_PDF.FM
30.8.02
Electric parts list
Pos. Designation Articel designation Order-no./ Ident-no.
1 A2 power controller
IM-651
2 A3.1 soldering terminal MP 12
00062010
3 A4 basic module
IM-880
4 A4.1 ballast module
IM-051
5 A5 emergency stop switch-safety module
PNOZ X5
6 A6 emergency stop switch-safety module
PNOZ X5
7 at A3.1 1N4..... 1A diode
K-013
8 EN4 encoder
IGV18-0001
9 F1 fuse 5x20T4,0A 802285
802285
10 F3 automatic circiut breaker 1-pole-C6A
FAZNC6
11 Key pad membrane keyboard
IM-556T
12 K1 contactor
3RH1122-1B1340
13 K4 relay with plug connection 24V *
socket with screw terminal for 55.31-32-34
55.34.9.024.004
94.44.1
14 Q1 electricial
main switc
main switch K&M
T0-2-1/EA/SVB
15 R1 resistor 470 Ohm 1/4 Watt
K-000WIDERSTAND
16 R2 resistor 1,8K 1/4W
K-042WIDERST.1.
17 S01 emergency stop switch-button K&M 072370
emergency stop switch Kontaktelement K&M
090401
emergency stop switch Schild deutsch/
englisch K&M 058874
Q25PV
E01
SQT1
18 S10 proximity sensorM8x1 NJ1,5-8GM40-E2 on
call
15176
19 S11
PCB-clamp
selector switch
contact 1Sr 1O 22/30mm
D1G3S
DA11
20 S13 microswitch 6A (1005.0401)
13.537.12
21 S14 microswitch 6A (1005.0401)
13.537.12
22 S03 position limitation switch 1s 1ö
3SE3200-1D
23 S04 position limitation switch 1s 1ö
3SE3200-1D
24 S2 / S2.1 proximity sensorM8x1 NJ1,5-8GM40-E2
15176
25 S3 / S3.1 proximity sensorM8x1 NJ1,5-8GM40-E2
15176
