Chapter 8 Electrical and Pneumatic Equipment
8-1
E1 Semi-automatic screen printer
System Manual
EKRA / Doku Eisermann 08_ELEKTRO_PNEU_PDF.FM
30.8.02
8 Electrical and Pneumatic Equipment
Electrical equipment
Control cabinet
Fig. 14. Control cabinet
Control desk
Fig. 15. Control desk
A3A6A5F1A3.1X2.0A4
X4.1 A2 X2.1 A4.1 X1.0 K4 T1 F3 K1
Control panel
Emergency stop
Squeegee pressure
Pressure reducer
squeegee pressure
indicator
