Ekra E1 - Parts Lists and Drawings

Chapter 8 Electrical and Pneumatic Equipment
8-9
E1 Semi-automatic screen printer
System Manual
EKRA / Doku Eisermann 08_ELEKTRO_PNEU_PDF.FM
30.8.02
Pneumatic parts list
Pos. Designation Articel designation Order-no./ Ident-no.
1 X6 valve terminal-E1 SS5Y3-45NFD-7B-C4
V100770
SS5Y3-45NFD-7B-
2 Y16 pressure regulator G1/8
gauge G1/8 0-10 bar
mounting angle
pressure regulator G1/8
gauge G1/8 0-10 bar
EAR2000-F01
K8-10-40
B220
3 Y17 mounting angle EAR2000-F01
K8-10-40
B220
4 Y13/Y18 / Y19 / Y20 main air / service unit (complete)
LFR-1/8-D-Mini-KD
HE-1/8-D-Mini
185743
162806
5 Screen clamping valve SV-3-M5
selector switch N-22 S black
006817
009301
6 Display squeegee
pressure
gauge 1/8"NW40/0-4bar 304/40
7 Y14 Squeegee pres-
sure
pressure regulator 0,07-4,0 11-818-100 11-818-100
