Ekra E1 - Pneumatic System Components

Chapter 8 Electrical and Pneumatic Equipment
8-6
E1 Semi-automatic screen printer
System Manual
EKRA / Doku Eisermann 08_ELEKTRO_PNEU_PDF.FM
30.8.02
Pneumatic equipment
Printing nest
Fig. 24. Printing nest
Service unit and pressure adjustment
Fig. 25. Service unit and pressure adjustment
Z4
Z5
Z6
Z7
Service unit
Pressure regulator
main pneumatic connection
Pressure regulator
Pressure regulator
screen clamping
film tensioning frame
