Chapter 8 Electrical and Pneumatic Equipment
8-8
E1 Semi-automatic screen printer
System Manual
EKRA / Doku Eisermann 08_ELEKTRO_PNEU_PDF.FM
30.8.02
Valve terminal
Fig. 28. Valve terminal
Note:
Other pneumatic components, such as cylinders and linear units, are
included in the mechanical parts lists.
Note:
In the case of the Picoline VTE6 and VLT15 options and the venturi
suction option, the valves are included in the mechanical parts list.
X6
To Next Page
