Ekra E1 - Machine Components Overview

Chapter 3 Description of the Machine
3-2
E1 Semi-automatic screen printer
System Manual
EKRA / Doku Eisermann 03_SYSTEM_PDF.FM
30.8.02
Overview of the machine components
Front of machine
Fig. 3. Front of machine
1 Main switch 7 MOPS cameras
2 Cleaning flap 8 Keypad
3 Snap-off and pneumatic settings on* right-
hand side
9 Emergency-stop switch
4 Protective cover 10 Control desk
5 Print area 11 Printing table guideway
6 Screen for manual optical positioning sys-
tem (MOPS)
12 Foot switch
4
10
9
8
7
6
5
3
2
1
11
12
