Parts List 2699000003
Vacuum pin
Date of
design:
27.06.2001 Date of change: 10.01.2002 Drawing
75011
Variation: a = 5 Pin
b = 10 Pin
Item Var. Quant. Designation Dimension Article
10 1,00
piece
angle L30*100*5*138 4056000098
20 1,00
piece
divider 25*25*138 4054000062
30 a 5,00
piece
pin 13*25.4 4035000011
35 b 10,00
piece
pin 13*25.4 4035000011
50 1,00
piece
sheet metal 2*60*191 4040000233
120 a 5,00
piece
venturi nozzle plugable suction
connector.da=4mm,
air connector di=4mm
5690000014
125 b 10,00
piece
venturi nozzle plugable suction
connector.da=4mm,
air connector di=4mm
5690000014
130 a 5.000,00
mm
polyurethan-tube da=4; di=2.6 5671000002
135 b 10.000,00
mm
polyurethan-tube da=4; di=2.6 5671000002
140 500,00
mm
polyurethan-tube da=6; di=4 5671000005
170 1,00
piece
5/2-magnet valve MVH-5-1/4-S-B
air pressure control
5630160001
180 1,00
piece
push-in fitting angle di=6 thread R1/4 5673000035
190 2,00
piece
screwed sealing plug DIN 908-G1/4A-St 5677000011
200 a 10,00
piece
push-in fitting straight di=4 thread M5 5673000024
205 b 20,00
piece
push-in fitting straight di=4 thread M5 5673000024
210 1,00
piece
push-in fitting angle di=6 thread R1/8 5673000033
220 2,00
piece
plug in connection ramification di=6 of
di=6
5673000034
230 1,00 silencer connection G1/8 outside 5690000012
Seite/Page 1
