Ekra E1 - Drive Motors and Position Sensors

Chapter 8 Electrical and Pneumatic Equipment
8-4
E1 Semi-automatic screen printer
System Manual
EKRA / Doku Eisermann 08_ELEKTRO_PNEU_PDF.FM
30.8.02
Table drive motor, view from rear
Fig. 20. Table drive motor, view from rear
Table loading position sensors
Fig. 21. Table loading position sensors
M3
S2
S2.1
