Chapter 3 Description of the Machine
3-13
E1 Semi-automatic screen printer
System Manual
EKRA / Doku Eisermann 03_SYSTEM_PDF.FM
30.8.02
Fiducials 2 fiducials or any required structures in PCB layout
Fiducial size
0.7 - 3 mm
2
Fiducial position Anywhere in area of PCB
Performance
Generation of a program >5 min
Product changeover > 5 min
Machine control
Hardware Microprocessor-controlled; LCD display
Memory 100 PCB profiles
General data
Electrical connection 230 V / 50 Hz / 1 kW
Pneumatic connection 6 - 10 bar
Width x depth x height 1270 mm x 1100 mm x 1420
Working height 850 mm ± 25 mm (adjustable)
Weight 350 kg
Permissible operating
temperature
+10°C - +40°C
Relative air humidity 30 - 90%
