Chapter 5 Operation
5-6
E1 Semi-automatic screen printer
System Manual
EKRA / Doku Eisermann 05_BEDIEN_PDF.FM
30.8.02
 Confirm your selection of the printing mode by pressing ENTER
.
 Start a printing process by pressing the foot switch.
⇒ The printing table moves to the printing position and the printing pro-
cess starts.
 Press the Stop button .
 Press the squeegee up/down button .
 The rear squeegee is lowered.
 Open the cover.
 Turn the micrometer until the squeegee is touching the stencil.
 Turn the micrometer another 1 to 2 revolutions (2 revolutions = 1mm
adjustment distance), depending on the squeegee type (lowering the
squeegee).
 Close the cover.
 Press the Stop button again.
⇒ The printing cycle is resumed.
 When the squeegee unit travels to the rear again, press the Stop button
once more.
 Press the squeegee up/down button .
 The front squeegee is lowered.
 Open the cover.
 Turn the micrometer for the front squeegee until the squeegee is touch-
ing the stencil.
 Turn the micrometer another 1 to 2 revolutions (2 revolutions = 1mm
adjustment distance), depending on the squeegee type (lowering the
squeegee).
 Close the cover.
 Press the Stop button again.
⇒ The printing cycle is ended .
STOP
STOP
STOP
STOP
