Ekra E1 - Page 83

Parts List 2213000003
Screen clamping E1
Date of
design:
28.03.2001 Date of change: 12.09.2001 Drawing
77859E
Variation:
Item Var. Quant. Designation Dimension Article
10
2,00
piece
angle L50*45*10*170 4056000056
20 4,00
piece
cylinder holder 50*20*80 4052000085
30 2,00
piece
angle L50*50*5.5*60 4056000057
40 2,00
piece
Item-profile 5 40*20 40*20*830 4010000045
50 2,00
piece
ledge 50*4*830 4054000040
60 1,00
piece
ledger 15*10*40 4053000074
70 1,00
piece
holder L40*30*3*70 4056000058
150 4,00
piece
print plate EV-15/63-DP 5027020002
160 4,00
piece
tightening unit EV-15/63 stroke 4mm 80*23*18 5027020001
170 2,00
piece
adjustable clamp lever with screw M5 4090000008
180 2,00
piece
adjustable clamp lever with screw M6 4090000009
190 1,00
piece
knurled head screw M5*16 ,plastic 5024050002
200 4,00
piece
cover 40*20 for profile 5 5070600001
Seite/Page 1
© EKRA
10.04.02
