Parts List 2216000001
Squeegee device E1 stroke 60
Date of
design:
19.04.2001 Date of change: 16.05.2001 Drawing
77844E
Variation:
Item Var. Quant. Designation Dimension Article
10
2,00
piece
angle 52*52*166 4053000083
20
1,00
piece
plate 100*6*160 4052000097
30
2,00
piece
stud bolt 12*50 4034000011
40
1,00
piece
traverse 40*220*3*695 4050000010
50
2,00
piece
holder 43*22*240 4054000047
60
2,00
piece
ledge 50*10*230 4054000048
70
2,00
piece
plate 40*5*80 4052000098
80
2,00
piece
casing sheet 1*170*270 4040000135
90
1,00
piece
safety guard 1.5*20*302 4040000136
120
2,00
piece
pressure piece 10*12 4039000005
130
4,00
piece
pressure bolt 9.8*19 4034000012
180
4,00
piece
knurled head screw 15*76 4039000011
190
4,00
piece
threaded bushing 17*32 4039000012
260
1.200,00
mm
energy chain series 06 E2 B=16.5 R=28
black
5090010005
270
2,00
piece
connection element series 06 E2 B=16.5 5090110004
280
2,00
piece
knurled head screw DIN 464-M3*25-St-
zinced
3*25 5050000049
290
4,00
piece
knurled head screw DIN 464-M3*10-St-
zinced
3*10 5050000050
300
2,00
piece
adjusting screw 25mm/0.01 with tension
nut
5028000002
310
4,00
piece
cylinder with guid piston 25mm, stroke
60mm, double acting
5601040006
