Ekra E1 - Page 90

Parts List 2297000001
Casing E1
Date of
design:
30.03.2001 Date of change: 05.12.2001 Drawing
77325
Variation:
Item Var. Quant. Designation Dimension Article
10
1,00
piece
mounting sheet metal, curved 2.5*665*775 4040000134
30 2,00
piece
plate 40*10*46 4052000099
40 1,00
piece
holder 30*5*45 4052000100
50 1,00
piece
switching cam 12*56 4036000016
60 2,00
piece
distance 18*213 4033000014
70 1,00
piece
distance 18*100 4033000015
80 1,00
piece
bearing 20*8*33 4057000007
90 1,00
piece
cover ring E1 4032000005
100 1,00
piece
panel housing 5392000005
110 1,00
piece
mounting sheet emtal 2.5*90*280 4040000137
120 1,00
piece
angle L100*40*5*40 4056000065
140 1,00
piece
angle 3*70*83 roh 4040000138
150 1,00
piece
security flap 2299000010
200 1,00
piece
valve 1.5*134*667 4040000139
210 1,00
piece
cover 1.5*93*750 4040000140
250 1,00
piece
DU-bush cylindric 5*7*5 5012070006
260 2,00
piece
magnet lock adhesive force 40N 5025000003
270 1,00
piece
safety switch with switching cam 76039B 5353000018
280 3,00
piece
hinge 8 PA (right) 5070300002
