Parts List 2283000012
Universal print nest 450mm
Date of
design:
27.06.2001 Date of change: 15.11.2001 Drawing
73632F
Variation:
Item Var. Quant. Designation Dimension Article
10
1,00
piece
ledge 20*25.4*450 4054000137
20 1,00
piece
stretching ledge 20*25.4*450 4054000138
30 1,00
piece
guidance ledge 30*25.4*450 4054000139
40 4,00
piece
plate 40*5*25.4 4052000186
50 1,00
piece
sheet metal 1.5*17.5*450 4040000245
60 1,00
piece
sheet metal 1.5*40*450 4040000246
70 1,00
piece
sheet metal 2*285*428 4040000241
80 2,00
piece
guidance bolt 10h6*74.5 4034000037
90 5,00
piece
magnet strip 450mm 2283000013
100 1,00
piece
cylinder fixing 20*15*120 4054000132
110 2,00
piece
sheet metal 2*117.5*428 4040000242
120 1,00
piece
sheet metal 17.5*1*450 4040000247
130 1,00
piece
sheet metal 1*40*450 4040000248
140 4,00
piece
pin ISO 28734-5*20-A-St 5*20 5055000010
150 4,00
piece
pin ISO 28734-3*8-A-St 3*8 5055000005
160 2,00
piece
spring DIN 2098-1.10*9.20*26.00
stainless
5023000011
170 4,00
piece
Polymer plain bearing 10*12*14.5 5012050001
180 1,00
piece
tightening unit EV-10/30 stroke 3mm 5027020003
190 1,00
piece
print plate EV-10/30-DP 5027020004
