Elmo MA-1 User Manual

64
◆HOW TO USE THE FIXING SCREWS
When installing the product to a desk
Use a M3 screw, with 0.5mm thread pitch, and 7-12mm long.
■Installation image
■Mounting dimension
M3 screwｘ2
M3 screw
M3 screw
Select an appropriate screw according to the thickness of the desk.
If the screw is too short, it is not possible to secure the product to the desk properly.
For example, when the thickness of the desk is 20mm, the screw length should be
27-32mm.
NOTE
