Control Station 0 networking worksheet
277
Setup Worksheets
EMC CONFIDENTIAL
Control Station 0 networking worksheet
You will need the following information for the Control Station 0 networking
configuration. This information is entered during
“Step 2: Install latest File OE on CS 0”
on page 139
.
If you need to change the private network addresses because of a conflict with the
customer’s public network, fill out the “Private LAN worksheet” on page 280 before
continuing.
Primary Internal (Private) Network Setup
Hostname: emcnas_i0
IP Address_____ . _____ . _____ . 100 (default 128.221.252.100)
Netmask: 255.255.255.0
IPMI Network Setup
Hostname: emcnas_ipmi
IP Address _____ . _____ . _____ . 100 (default 128.221.254.100)
Netmask: 255.255.255.0
Backup Internal (Private) Network Setup
Hostname: emcnas_i1
IP Address _____ . _____ . _____ . 100 (default 128.221.253.100)
Netmask: 255.255.255.0
Specify How to Set the Control Station’s Public Network Address
❑ Static IP Address
❑ BOOTP (Bootstrap Protocol; network must have BOOTP server)
❑ DHCP (dynamic host configuration protocol; network must have DHCP
server)
Configure TCP/IP (if Static IP Address selected)
IP Address _____ . _____ . _____ . _____
This is the IP address of port eth3 that is cabled to the customer’s public or
maintenance LAN.
Netmask _____ . _____ . _____ . _____
Default Gateway (IP) Address _____ . _____ . _____ . _____
Primary Nameserver _____ . _____ . _____ . _____
Configure Network
Domain Name ___________________________________________
This is the domain name of the customer’s network to which the Control
Station is attached.
Hostname _______________________________________________
Secondary Nameserver (optional) _____ . _____ . _____ . _____
Tertiary Nameserver (optional) _____ . _____ . _____ . _____
