Private LAN worksheet
281
Setup Worksheets
EMC CONFIDENTIAL
Backup private LAN
Table 15 lists the default backup private LAN addresses. The backup private LAN
shares the Ethernet switch with the primary private LAN.
The netmask is always 255.255.255.0.
IPMI private LAN
Table 16 lists the default IPMI private LAN addresses. This subnet is used only for
VNX gateways with two Control Stations, and consists of a crossover cable
connecting CS 0 and CS 1.
The netmask is always 255.255.255.0.
Table 15 Backup private network addresses
Component
Name in
/etc/hosts Default address New IP address
Control Station emcnas_i1
128.221.253
.100
________.________._______
.100
Blade 2 server_2b .2 .2
Blade 3 server_3b .3 .3
Blade 4 server_4b .4 .4
Blade 5 server_5b .5 .5
Blade 6 server_6b .6 .6
Blade 7 server_7b .7 .7
Blade 8 server_8b .8 .8
Blade 9 server_9b .9 .9
Table 16 IPMI private network addresses
Component Name in/etc/hosts Default address New IP address
Control Station 0 emcnas_ipmi
128.221.2
54
.100
________.________._______
.100
Control Station 1 emcnasotherIPMICS_i3 .101 .101
