Setup Celerra wizard worksheets

287

Setup Worksheets

EMC CONFIDENTIAL

Data Mover 4 (server_4) network services

DNS Domain Name 1 ________________________________________

DNS Servers for that domain

_____________________________________

DNS Domain Name 2 ________________________________________

DNS Servers for that domain

_____________________________________

DNS Domain Name 3 ________________________________________

DNS Servers for that domain

_____________________________________

Protocol:

❑ UDP ❑ TCP

NIS Domain Name __________________________________________

NIS Servers

_____________________________________
