Connect Cables for a Direct-connected VG2
79
EMC CONFIDENTIAL
5
After the components are installed in a cabinet, the next step is to connect the
remaining cables. If the VNX VG2 gateway was installed in a cabinet at the factory,
most cables are already connected; just verify the cables are connected as shown in
this chapter and ensure that all of the connectors are fully seated.
Note: Skip this chapter if you are not installing a direct-connected VG2 gateway.
Ensure that you install the cables in the order shown. Do not connect the blade's
power cables until directed to do so in the software installation chapter:
â—† Step 1: Blade Fibre Channel cables ............................................................................. 80
â—† Step 2: Serial cables ....................................................................................................... 83
â—† Step 3: Optional tape backup device cables .............................................................. 84
â—† Step 4: Private LAN cables........................................................................................... 85
â—† Step 5: External network cables................................................................................... 87
Connect Cables for a
Direct-connected
VG2
