Connect Cables for a Fabric-connected VG8
EMC CONFIDENTIAL
Figure 56 Blades connected to a single switch
Record the switch ports you connect in the “FC/FCoE cabling worksheet” on
page 273.
Note: It is recommended that you label each end of the FC cable with the blade number, I/O
module, port name, FC switch port number, and FC switch number, before you connect the
cable.
Blade 5
Blade 4
Blade 3
Blade 2
1
2
3
4
5
6
7
8
SFP
SFP
SFP
SFP
SFP
SFP
SFP
SFP
Blade 9
Blade 8
Blade 7
Blade 6
9
10
11
12
13
14
15
16
SFP
SFP
SFP
SFP
SFP
SFP
SFP
SFP
CNS-001851
Fibre
Channel
Switch
Port 0
Port 1
Port 0
Port 1
Port 0
Port 1
Port 0
Port 1
Port 0
Port 1
Port 0
Port 1
Port 0
Port 1
Port 0
Port 1
