72 Chapter 6 Parameter Descriptions
24: In the terminal control mode of the drive (F002 = 1), when X7 is not set to
24, the door is controlled by the external door control signals. When set to 24,
the X7 is defined as the operation enabling signal input terminal, and the
external door control is enabled only when X7 signal is valid. If X7 signal is
invalid, the inverter will stop immediately when in the operation state, or does
not respond when in the stopping state.
F104 Function of programmable relay output PA/PB/PC
Range: 0~9
【
4
】
F105 Function of programmable relay output PAC/PC1
Range: 0~9
【
0
】
F106 Function of programmable relay output PAC/PC2
Range: 0~9
【
1
】
Functions of programmable relay are shown in Table 6-3.
Table 6-3 Relay output functions
Settings Functions Settings Functions
0
Output signal 0 for
complete OD
5 Fault relay output 2
1
Output signal 0 for
complete CD
6
Output signal 2 for
complete OD
2
Output signal 1 for
complete OD
7
Output signal 2 for
complete CD
3
Output signal 1 for
complete CD
8 Locking signal output
4 Fault relay output 1 9 Re-opening signal output
Notes about the functions:
0: Output signal 0 for complete OD
In OD process, when the drive receives OD location limiting signal or when
the pulse count number reaches the OD location limiting value, the drive will
output "0" for complete OD.
Complete OD signal is disabled in demo mode, general-purpose drive
operation mode and CD process.
1: Output signal 0 for complete CD
In CD process, when the drive receives CD location limiting signal or when
the pulse count number reaches the CD location limiting value, the drive will
output "0" for complete CD.
