104 1019567 REV. 03
5.5.10 Air Cylinder
To remove the Air Cylinder you will need two open-ended wrenches. Table 5.3 Air Cylinder
Part Numbers lists the Air Cylinder part numbers and the wrenches needed to remove an
Air Cylinder.
WARNING General Warning
Before servicing the welder, make sure to do the following:
1. Turn off the welder and unplug main power.
2. Turn air pressure to zero and disconnect your main air line connection.
Failure to do this leaves the welder under potentially dangerous air
pressure.
3. Wait approximately 2 minutes after unplugging the welder before touching
internal electrical components.
Table 5.3 Air Cylinder Part Numbers
Air Cylinder Size Part Number Wrench Size
2-1/2 in. x 4 in. 100-246-576 3/4 in. and 1/2 in.
3 in. x 4 in. 100-246-573 3/4 in. and 5/8 in.
NOTICE
These Air Cylinder Part Numbers are for replacement. If you are
converting to another cylinder size, contact Branson Product Support
for the correct conversion kit.
