Emerson 2000IW - Troubleshooting Charts; Table 4.1 Fuse;Circuit Breaker Troubleshooting; Table 4.2 Fan Troubleshooting

1019567 REV. 03 51
4.2 Troubleshooting Charts
4.2.1 Fuses/Circuit Breaker
4.2.2 Fans
NOTICE
Do not reset a plant or welder circuit breaker more than once without
further troubleshooting.
Table 4.1 Fuse/Circuit Breaker Troubleshooting
Problem Cause/Solution Refer to
Plant fuse fails or plant
circuit breaker trips when
plugging the welder into an
electrical outlet.
Inspect line cord assembly;
replace if faulty.
N/A
Plant fuse fails or plant
circuit breaker trips during
weld cycle.
Check rating and load of
plant electrical system.
N/A
Welder circuit breaker (CB1)
trips.
Check fan motor; replace if
faulty.
Chapter 5: Assembly/
Disassembly
NOTICE
Do not reset a plant or welder circuit breaker more than once without
further troubleshooting.
Table 4.2 Fan Troubleshooting
Problem Cause / Solution Refer to
Fan does not work; power
On/Off indicator light is On.
Check fan motor; replace if faulty.
Chapter 5:
Assembly/
Disassembly
Check DC Supply
Check line voltage. N/A
