Emerson 2000IW - Opening and Removing the Left Side Cover (EDP 100-032-338); Figure 5.2 Opening the Left Side Cover

1019567 REV. 03 67
5.3 Opening and Removing the Left Side Cover (EDP 100-
032-338)
Figure 5.2 Opening the Left Side Cover
WARNING General Warning
Before servicing the welder, make sure to do the following:
1. Turn off the welder and unplug main power.
2. Turn air pressure to zero and disconnect your main air line connection.
Failure to do this leaves the welder under potentially dangerous air
pressure.
3. Wait approximately 2 minutes after unplugging the welder before touching
internal electrical components.
