5. Use an Allen wrench to remove the two shipping spacer retaining screws (Figure 5.34 Shipping
Spacers)
6. Plug the encoder cable connector into socket J42 on the Control Module
7. Install tie wraps to attach the encoder cable to the Main Harness
8. Close the left side cover. See
5.3 Opening and Removing the Left Side Cover (EDP 100-032-338).
9. Install the two shipping spacers on the faulty encoder. Install each shipping spacer as follows:
• insert a retaining screw through the Body section (
Figure 5.34 Shipping Spacers)
• insert the shipping spacer between the sections (
Figure 5.34 Shipping Spacers)
• While pushing down on the screw; slide the Read section until the screw catches in the shipping
spacer hole; and tighten the screw
10.Return the failed encoder to Branson's repair department
CAUTION General Warning
Make sure you install enough tie wraps so the encoder cable does not
get pinched by carriage movement.
