1019567 REV. 03 53
No ultrasonic power to horn during weld
cycle. The following conditions exist
during the weld cycle:
• Overload alarm (Error 18 IW, Error 19
IW+) displayed
• POWER BARGRAPH displays brief or no
indication;
• welder completes weld cycle; and
• welder tunes properly
Check or reduce air
pressure.
2000 IW/IW+
Operating Manual
Check or reduce
Dynamic Trigger
setting.
Check booster;
replace if faulty.
Consider using
Pretrigger option.
Reduce the horn
DOWN SPEED (adjust
DOWN SPEED control
setting)
Recondition
Converter-Booster-
Horn Stack mating
surfaces.
6.1.1
Reconditioning the
Stack (Converter,
Booster and Horn)
Check horn; replace if
faulty
2000 IW/IW+
Operating Manual
Check converter;
replace if faulty
Output Control option
set too low.
N/A
No ultrasonic power passed to horn
during weld cycle. The following
conditions exist during the weld cycle:
• POWER BARGRAPH displays brief or no
indication;
• welder runs in TEST mode; and
• welder tunes properly
Main air supply too
low. Check main air
supply.
2000 IW/IW+
Operating Manual
Adjust mechanical
stop.
Dynamic Trigger
setting too high;
adjust setting.
Horn DOWN SPEED
too low. Adjust DOWN
SPEED control.
Pressure Gauge
setting too low. Adjust
setting.
Check Trigger Switch
(TRS). Replace if
faulty.
Chapter 3:
Schematics
Chapter 5:
Assembly/
Disassembly
Table 4.3 Ultrasonic Power Troubleshooting
Problem Cause/Solution Refer to
