1019567 REV. 03 61
Error 26 x
START SWITCH 2 Lost Non-
Latching - START SWITCH 2
was lost before the trigger
became active.
• Check START SWITCHES and
remote START switches
• Make sure to keep pressing
both START SWITCHES until
triggering occurs
• Check Controller Module;
replace if faulty
Error 27 x
SV Safety Error Non-
Resettable - SV drive safety
circuit is not working. This
error cannot be cleared by
RESET, or by the external
RESET input.
• Check Controller Module;
replace if faulty
WARNING
Do not replace, repair or modify any part of the SV Safety Circuit.
Error 28 x
START SWITCH 2 Stagger
Error Non-Latching - START
SWITCH 2 was not pressed
within 200 ms after START
SWITCH 1 was pressed.
• Press both START SWITCHES
simultaneously
Error 29 x
START SWITCH 1 Stagger
Error Non-Latching - START
SWITCH 1 was not pressed
within 200 ms after START
SWITCH 2 was pressed.
• Press both START SWITCHES
simultaneously
Error 30 x
Time Limit Error Latchable -
Minus time limit not
reached.
• Change -Limit value
• Contact Branson Applications
Lab
Error 31 x
Collapse Limit Error
Latchable - Plus collapse
limit exceeded or minus
collapse limit not reached.
• Increase Collapse window
• Contact Branson Applications
Lab
Error 32 x
Absolute Limit Error
Latchable - Plus absolute
limit exceeded or minus
absolute limit not reached,
or weld aborted because of
overload.
• Increase Absolute window
• Contact Branson Applications
Lab
Error 33 x
Time Limit Setup Error
Latchable - Value for minus
limit greater than value for
plus limit, or minus limit
greater than nominal value,
or plus limit less than the
nominal value.
• Check -Limit and +Limit
values
• Check Weld Time
• Contact Branson Application
Lab or Local Branson
representative
Table 4.6 Error Codes
Error
Code
IW IW+ Description Cause/Solution
