G3 Series EtherCAT
TM
Technical Manual
10-97
TDG3ECM1-5EN 07/2020
Subject to change without notice
www.asco.com/g3
One 4-20ma Analog Input + One 4-20 Analog Output per Connector M12 Female Modules
Module
Part No.
Signal Type
Short Circuit
Protection
Short Circuit / Power
Present Status Bits
Input Channels
Output Channels
240-363 4-20 mA YES YES (4) Selectable 4 4
Diagnostic Mapping
BYTE Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
X
(Selectable)
Allocated
and
Reserved
Allocated
and
Reserved
Allocated
and
Reserved
Allocated
and
Reserved
Power/
Short Status
for Conn. D
Power/
Short Status
for Conn. C
Power/
Short Status
for Conn. B
Power/
Short Status
for Conn. A
X + 1
(Selectable)
High Alarm
for Conn. D
Input
Low Alarm
for Conn. D
Input
High Alarm
for Conn. C
Input
Low Alarm
for Conn. C
Input
High Alarm
for Conn. B
Input
Low Alarm
for Conn. B
Input
High Alarm
for Conn. A
Input
Low Alarm
for Conn. A
Input
X + 2
(Selectable)
High Alarm
for Conn. D
Output
Low Alarm
for Conn. D
Output
High Alarm
for Conn. C
Output
Low Alarm
for Conn. C
Output
High Alarm
for Conn. B
Output
Low Alarm
for Conn. B
Output
High Alarm
for Conn. A
Output
Low Alarm
for Conn. A
Output
Pin 1 = +24VDC
Pin 2 = Output
Pin 3 = 0 VDC
Pin 4 = Input
Pin 5 = Not Used
