14 E300 Design Guide
Issue Number: 1
2.4.2 Power and current ratings (derating for switching frequency and temperature)
Table 2-4 Maximum permissible continuous output current @ 40 °C (104 °F) ambient
Model
Heavy Duty
Nominal rating Maximum permissible continuous output current (A) for the following switching frequencies
kW hp
2
kHz
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
200 V
03200106 2.2 3.0 10.6 TBC TBC
04200137 3.0 3.0 13.7 TBC TBC
04200185 4.0 5.0 18.5 TBC TBC
05200250 5.5 7.5 25 TBC TBC
06200330 7.5 10 33.0 TBC TBC
06200440 11 15 44.0 TBC TBC
07200610 15 20 61 TBC TBC
07200750 18.5 25 75 TBC TBC
07200830 22 30 83 TBC TBC
400 V
03400062 2.2 3.0 6.2 5.8 TBC TBC
03400078 3.0 5.0 7.8 6.0 TBC TBC
03400100 4.0 5.0 10 6.0 TBC TBC
04400150 5.5 10 15.0
12.8
TBC TBC
04400172 7.5 10 17.2 TBC TBC
05400270 11 20 27 20.2 TBC TBC
05400300 15 20 30 26.5 TBC TBC
06400350 15 25 35
27.1
TBC TBC
06400420 18.5 30 42 TBC TBC
06400470 22 30 47 TBC TBC
07400660 30 50 66
66
TBC TBC
07400770 37 60 77 TBC TBC
07401000 45 75 100 TBC TBC
